  • Products Details
Detailed Product Description
Model Number: MFP-85WA-B Type: Horizontal Fan Coil Unit
Rated Cooling Capacit: 5KW Rated Heating Capacity: 7.9KW
Air Volume: 500m3/h Size: 944×492×252
High Light:

hvac fan coil unit

,

indoor fan coil unit

2-tube , air return box optional, Horizontal Fan Coil Unit 500CFM, CE certificated, low noise , with built-in pump

Horizontal Fan Coil Units, with cross flow fan, it features low noise, stable operation, high efficiency, good looking appearance, slim body and various operation modes to be selected. Furthermore, long distance monitoring and other control functions are available. It is widely used in office, hotel and villa.
It has an elegant and novel appearance with automatic drainage and can be installed on the floor or under the ceiling. With the features of easy and flexible installation, wide range and long-distance air supply, good performance, various control functions and slim body, it is especially applicable to the hotel, office, meeting room with low space room.



Main features
1) FRAME AND STRUCTURE
Panels and frame are made of galvanized steel, properly punched and punched for fixing both accessories and the unit itself.
2) COOLING OR HEATING COIL
The coils are made of seamless tubes expanded into aluminum fins in continuous block. The connections have brass headers with female fittings and provided with easily accessible vent and drainage valve.
3) FAN DECK
The fan decks are YILIDA brand, best made in China, and composed of double suction centrifugal fans with aluminum impellers and 3-speed fan motors. Each fan motor assembly is dynamically balanced.
4) DRIP TRAY
The drip trays are made from sheet metal treated with polyester powder coating to ensure total resistance to atmospheric agents. Yilida brand.
5) FILTER
The easily removable filter is made of filtering honeycomb polypropylene fabric and supported by an aluminum frame.
The filter is installed on the units with plenum only.
6) ELECTRICAL CONNECTION BOX
All electric wires are connected to enclosed electrical terminal block, situated on the same side of the water connections.



Characteristic

1. Low noise.
2. Easy installation.
3. Special design of air filter.
4. Air flows: 200 to 2380m3/h.
5. Cooling capacity range: 1.8 to 14kw.
6. Power supply: 220v,50hz, and 1 ph depends on the different country.
7. Application: Industry, hotel, commercial building, etc.
8. Function: Cooling and heating.
9. Test condition for rated refrigerating output of fan coil unit.




Specifications for Horizontal Fan Coil Unit:

1. Air flow 850CFM, 500CMH
2. Cooling capacity 5Kw Heating capacty 7.9Kw
3. Static pressure 12Pa, 30Pa, 50Pa is optional.
4. Two pipe/tube system
5. AC motor , BLDC brushless motor optional
6. Left pipe or right pipe is optional.
7. Thickness of the unit is 235mm only.
8. Air return direction from back or bottom optional.
9. Plenum and filter is optional
10. Thermostat or valve is optional.



Model MFP-85WA-B
Air flow-CMH 850
Air flow-CFM 500
Cooling capacity -W 5000
Heating capacty W 7900
Unit net dimentions 944×492×252
Power supply 220V,50Hz,1Ph
Piping Two pipe/tube system
Air return type Rear return or bottom return optional.
Static pressure 12Pa, 30Pa, 50Pa optional.
Return box&filter Plenum box or filter is optional
Pipe direction Left or right optional and changable at site
Thickness 235mm
Motor type AC motor BLDC brushless optional
Thermostat 3 speed, 0-10Vmodulating thermostat, or Modbus thermostat optional.
Valve Two way valve or three way valve optional.
Testing condition-Cooling Dry ball 27℃ wetball 19.5℃ 7℃ in 12℃ out
Testing condition-Cooling Dry ball 20℃ 50℃ in 40℃ out


Testing condition:
2-tube system
Cooling
Entering air temperature: Dry bulb 27ºC, Wet bulb 19.5ºC
Entering/out water temperature: 7ºC/ 12℃
Heating
Entering air temperature: 20ºC
Entering water temperature: 60ºC, Same water flow rate as for the cooling


All equipment wiring complies with CE requirementsReliability Features
· Base units are CE certified for EU standards
· All units with auto-restart functions.

Maintenance Features
· Integrated Condensate Water drain Pump
· With Built-in Overflow Safety Devices
· Reusable wire framed filters can be vacuum cleaned



Product certification:

Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 0Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 1




Standard Warranty

18 months since delivery date.

supply 1% free parts with shipment.

fan motor P.C.B reciever Board sensor

trans

former

fan motor capacitor remote controller wire controller
water level switch fan drain tray swing motor drain pipe panel filter corner board of panel


Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 2Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 3Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 4
Energy Saving Horizontal Fan Coil Unit 500CFM Stable Operation Easy Installation 5



Packing and shipping

Normally we use carton packing. The carton box printed with our MECO brand and unique color and pattern. We also have strong packing as optional. Depends on customers needs, we have crates, pallets, or honeycomb box etc. Our FOB port is NINGBO, China port.



Field-Installed optional Accessories:

· 2 & 3 way valves and with the actuators

· Wall Mounted Mechanical or Digital Thermostat
· Wall Mounted Digital Thermostat with Modbus function
· Wall Mounted Digital Thermostat with WIFI control function



FAQ.
Q:Can you make OEM brand orders?
A: Yes of course. As a specialized manufacturer and exporter for this product in China, we sincerely hope to establish business relations with your esteemed corporation. Now we do OEM/ODM for a lot of famous brands in China and other countries, such as YORK, CIAC, KingAir, QingHuaTongFang,TCL,AUX,CHIGO,LS,etc.

Q: How long is your warranty?
A: We offer 18 months warranty for our products. We offer 1% free repair parts and professional technical support.

Q: Our hotel want to choose the fan coil unit which have 4 pipe system, do you have this one?
A: Yes, Most of our products have 4 pipe system as optional.

Q: Do you have selection software for your FCU?
A: Not yet now. But we can select the units for you based on your given selection request.
