Detailed Product Description
Type: θερμοστάτη Model: Wifi Thermostat
Type: Fan Coil Unit Condition: New
Mounting: Ceiling Mount After-sales Service Provided: Engineers Available To Service Machinery Overseas
High Light:

fcu thermostat

,

digital room thermostat

FCU Fan Coil Unit Thermostat



Feature:

   Digital LCD display room temperature and set point
• Cool/Heat/Fan Mode Control
• 3-Fan Speeds Select & Auto Fan
• 0-10V for valve control/fan speed control(Optional)
• 2 pipe or 4 pipe system
• Clock(Optional)
• Keycard (Optional)
• External sensor (Optional)
• Modbus(Optional)
• Bacnet(optional)



Specification:

Supply Voltage: AC24V; AC85-260V/AC24V,50/60Hz
• Temperature Sensor: NTC 10K
• Setpoint Range: Default 5~35℃
• Accuracy: ±1℃
• Backlight: White
• Control Performance: ON/OFF control or Modulating
• Thermostat Output: SPST replay for 2-pipe models
• 2 SPST replay for 4-pipe models
• Switch Current Rating: 2A(Resistive), 1A(Inductive)
• Operating Enviroment: 0~45℃
• Humidity: 5~95% RH (non-condensing)
• Cover: PC+ABS
• Mounbting: Embeded mounting, standard 86*86
junction box(hole pitch:60mm)
• Protection Class:IP30



FCU Fan Coil Unit Thermostat Ceiling Mount High Accuracy White Backlight 0FCU Fan Coil Unit Thermostat Ceiling Mount High Accuracy White Backlight 1FCU Fan Coil Unit Thermostat Ceiling Mount High Accuracy White Backlight 2
