Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20

China Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20 supplier
Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20 supplier Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20 supplier Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20 supplier Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20 supplier

Large Image :  Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20

Product Details:

Place of Origin: china
Brand Name: EKON
Model Number: DRF

Payment & Shipping Terms:

Minimum Order Quantity: 50PCS
Price: USD
Packaging Details: standard export box
Delivery Time: 15-25days after payment
Payment Terms: T/T
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Type: Motorized Valve Model: 2way Or 3 Way Valve
Size: DN15 Or DN20 Material: Ceresin Wax Propeller

hot water motorized valve slim type, with small size for small space spring reset electric heating valve



DRF electric heating valve is available for central air conditioning and heating system's water opening and closing, control valve depends on the ceresin wax propeller to reset spring, when it woking, the thermostat give a signal of opening,then the motorized valve has power to activate, the cold water or hot water come into the fan coil for providing the cool or heat air. the motorized will stop , and at the same time the water can't flow into the coil when the set temperature is achieved,so the room temperature is maintained.



DRF electric heating valve adopts ceresin wax propeller,there is no noise during PTC heating actuation working. it has spring reset function.after the power is off, the valve is closed and the running place will be instructed by indication, the screw installation is very easy,fast and convenient,



Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20

Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20

Small Size Hot Water Coil Motorized Valve Slim Type Electric Heating Valve DN15 / DN20
