Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System

Good quality Ceiling Suspended Fan Coil Unit for sales
Good quality Ceiling Suspended Fan Coil Unit for sales
I'm Online Chat Now

Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System

China Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier
Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System supplier

Large Image :  Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System

Product Details:

Place of Origin: china
Brand Name: EKON
Model Number: 2way/3way valve

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: usd
Packaging Details: export box
Delivery Time: 15-25days
Payment Terms: T/T
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Material: Brass Type: Motorized Ball Valve
Technical: Ending Waterway Control Power: 24V Or 220V

Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System



For ending water way control, the thermostat can control motor, make the valve power/off by motor to make the medium current or disconnected, and make the fan coils blow co control the temperature automatically.

Water proof, dustproof function, leak proofness and tightness.

Short power-on time, energy-efficient, the motor has long using life.

Easy close pressure difference, tight closing.

Direct water flow, KVS value is much larger than common 2 way value.

Soft value opening.

Actuated by one-way motor, rest by spring



Power supply:240VAC,50/60Hz, or 24V is optional

Power:2W torque 2N.m

Nominal pressure:1.6MPa

Running time:40-50s

Working medium: water, fluid temperature 5-95℃

2.5Kv,3.5Kv and 4 Kv, G1/2,G3/4,G1

Ambient temp:0-65℃,10%-90% RH

Available for central air conditioning’s refrigeration or heating system pipe’s opeing or closeing.

The actuator and valve is connected by screw connection way, actuator can be installed next to the wall

Efficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe SystemEfficient Brass Material Motorized Ball Valve For Fan Coil Units 2 Pipe System / 4 Pipe System
